Our Equipment

We continually invest in the latest high-performance machinery and tooling to ensure that our team is equipped with the most current technology for optimal results. Speed, accuracy, and reliability are essential to maximizing our productivity and maintaining the highest quality standards for every product we deliver.

CNC Milling

Ameritech Die & Mold South Milling Centers
NameTypeTable SizeInfoQty
Hermle C32U 5-Axis 26" x 16.8" X-25.6", Y-25.6", Z-19.7", 24,000 RPM 1
Mazak Nexus 510 VMC 51" x 21.5" X-40",Y-22",Z-20" travels, 12,000 RPM 2
Mazak VTC 30C VMC 79" x 30" X-66",Y-30",Z-26" travels, 12,000 RPM 1
Mazak VTC 20B VMC 57" x 20" X-44",Y-20", Z-20" travels, 7,000 RPM 1
Hurco VM10i VMC 30" x 16" X-26", Y-16", Z-10" travels, 10,000 RPM
Fidia D165 HS VMC 55" x 31" X-39",Y-24",Z-20" travels, 30,000 RPM 1
Creative Evolution HSD-575 HS VMC 24" x 31.5" X-20", Y-30.5", Z-14", 30,000 RPM 1
Haimer Power Clamp Shrinker     Shrink-fit tool holders used throughout for precision high-speed applications 1



EDM Equipment

Ameritech Die & Mold South Robotic Sinker EDM
NameTypeTank SizeInfoQty
Fanuc Robocut A-1iE 5-Axis Wire EDM 52"x39"x12" 31.5"x23.6"x12.2" Travels 1
Mitsubishi EA28V Sinker EDM 41"x30"x14" 26"x18"x14" Travels - equipped with Erowa Robot Compact 80 1
Erowa Robot Compact 80 Robotic Changer  154 Stations Servicing Mitsubishi EA28V EDM and Creative Evolution HSD-575 High-Speed Milling Center 1
Erowa receivers and pallets     Used throughout for electrode and small insert automation 1
Westhoff Micro Flush Drill Machine       1

Turning Equipment

Ameritech Die & Mold South Turning Capabilities
NameTypeSizeInfoQty
Okuma LB3000 EXii Spaceturn 16" swing over bed 20" between centers Sub-spindle, 12-station turret, live tooling 1
Sharp 1860 Precision Lathe 18" swing over bed 60" between centers Precision Engine Lathe 1

Grinding Equipment

Surface Ground Core Insert on EDM Machine
NameTypeSizeInfoQty
Harig 618 surface grinder   6" x 18" Ball ways, digital readouts 2
Harig Grind-all Fixtures       2
Kuhn Herman Schmidt Radius Angle Dresser       1
Supertec 1224 wet surface grinder   12" x 24" Coolant 1
Chevalier 1224 wet surface grinder   12" x 24" Coolant 1
Deckel SO Cutter Grinder     Cutter Grinder 1

Welding Equipment

Welding

NameTypeSizeInfoQty
Miller 250 amp Heliarc     1

Sample Presses, Spotting Press & Cranes

Cincinnati Milacron Molding Press

NameTypeSizeInfoQty
LG 100-Ton Plastic Injection Molding Press   100 Ton   1
400-Ton Cincinnati Milacron Plastic Injection Molding Press   400 Ton   1
100-Ton Dake Spotting Press   100 Ton   1
Five-Ton Overhead Crane       1
6000-lb. Caterpillar Forklift       1
One-Ton Electric Lift Truck       1

Inspection & CNC Software

Coordinate Measuring Machine

NameQty
Brown & Sharpe Tesa Micro-Hite DCC 3D digitally controlled CMM (Coordiante Measuring Machine), 18" x 28" x 16.5" travels 1
Esprit CAM programming software by DP Technology 1
Mastercam CNC programming software 2
Solidworks 3D modeling design software 1
Cimatron CAD/CAM software for design and programming 3
Catia, Step, Iges data formats accepted
